2026 Ford Ranger Towing & Hauling Overview

2026 Ford Ranger Towing and Hauling Overview

The 2026 Ford Ranger combines midsize pickup versatility with the capability to handle trailers, equipment, and cargo. Properly equipped Ranger XL, XLT, and Lariat models can tow up to 7,500 pounds, while the Ranger Raptor offers a maximum available towing capacity of 5,510 pounds. Maximum available payload reaches 1,767 pounds on properly configured Ranger models, giving drivers useful capacity for gear in the truck bed. For more information about features that can support your time behind the wheel, visit our 2026 Ford Ranger Technology page.

• Max Available Towing: Up to 7,500 lbs on properly equipped Ranger models
• Ranger Raptor Towing: Up to 5,510 lbs when properly equipped
• Max Available Payload: Up to 1,767 lbs on properly configured Ranger models
• Trailer Tow Package: Available on XL, XLT, and Lariat

Maximum 7,500-Pound Towing Capacity

Properly equipped 2026 Ranger models can tow up to 7,500 pounds, providing capability for trailers, recreational equipment, and other towing needs. This maximum is available with the standard 2.3-liter EcoBoost engine in properly configured 4×2 and 4×4 models. The available 2.7-liter EcoBoost V6 can also support a maximum loaded trailer weight of 7,500 pounds when properly equipped. Actual towing capacity depends on the engine, drivetrain, equipment, passengers, cargo, and vehicle configuration.

• Up to 7,500 lbs of maximum available towing capacity
• 2.3-liter EcoBoost configurations can achieve the maximum rating
• Available 2.7-liter EcoBoost V6 configurations can also tow up to 7,500 lbs
• Trailer Tow Package required for trailers over 3,500 lbs

Trailer Tow Package and Towing Equipment

Ford offers the Trailer Tow Package on Ranger XL, XLT, and Lariat models for drivers who plan to take advantage of the truck’s higher towing capability. The package includes a Class IV trailer hitch receiver along with 4-pin and 7-pin trailer wiring connections. Ford specifies the Trailer Tow Package for towing trailers weighing more than 3,500 pounds, and properly equipped configurations can support up to the Ranger’s 7,500-pound maximum. Selecting the appropriate towing equipment is an important part of matching the truck to the trailer and load.

• Available Trailer Tow Package on XL, XLT, and Lariat
• Class IV trailer hitch receiver
• 4-pin and 7-pin trailer wiring connections
• Supports properly equipped Ranger configurations rated up to 7,500 lbs

Advanced Towing Technology

Available towing technology can help make maneuvering and controlling a trailer more manageable. The available Advanced Towing Package on XLT and Lariat includes an integrated trailer brake controller and Pro Trailer Backup Assist, along with the equipment included in the Trailer Tow Package. Pro Trailer Backup Assist is designed to help drivers steer a trailer while backing up by allowing them to indicate the direction they want the trailer to travel. Additional available equipment can include Rear Parking Sensors with Trailer Guidance and a 360-Degree Camera when appropriately configured.

• Available Pro Trailer Backup Assist
• Available integrated trailer brake controller
• Available Rear Parking Sensors with Trailer Guidance
• Available 360-Degree Camera on select configurations

Ranger Raptor Towing Capability

The 2026 Ranger Raptor pairs its off-road-focused engineering with useful towing capability. Its standard 3.0-liter EcoBoost V6 produces up to 430 lb-ft of torque and supports a maximum available towing capacity of 5,510 pounds when properly equipped. The Trailer Tow Package is standard on Ranger Raptor, providing factory-installed equipment for trailering. This gives Raptor drivers the ability to combine high-performance off-road capability with practical towing for recreational gear and trailers.

• Max Available Towing: 5,510 lbs
• Engine: 3.0-liter EcoBoost V6
• Max Available Torque: 430 lb-ft
• Trailer Tow Package standard on Ranger Raptor

Payload and Bed Capability

Towing is only part of the Ranger’s utility, since the pickup also provides useful capacity for cargo carried in the bed. Maximum available payload reaches 1,767 pounds with the 2.3-liter EcoBoost engine and 4×2 drivetrain, while payload ratings change with engine and drivetrain selection. The Ranger bed measures 59.6 inches long and 62.4 inches wide, with 48.2 inches of width between the wheel wells and 43.5 cubic feet of cargo volume. Drivers should account for passengers, accessories, cargo, and other added weight when determining how much payload capacity remains available.

• Up to 1,767 lbs of maximum available payload
• 59.6-inch bed length
• 48.2 inches of width between the wheel wells
• 43.5 cu ft of cargo volume

Choosing the Right Ranger for Towing and Hauling

The right Ranger configuration depends on the weight you plan to tow, the cargo you expect to carry, and the equipment you want on the truck. XL, XLT, and Lariat models can reach the 7,500-pound maximum available towing rating when properly equipped, while Ranger Raptor has a separate maximum available rating of 5,510 pounds. Drivers who tow frequently may also want to consider available features such as Pro Trailer Backup Assist and the integrated trailer brake controller. Checking the specific engine, drivetrain, packages, payload, and trailer weight before towing helps ensure the truck is properly configured for the job.

• Consider trailer weight when selecting a Ranger configuration
• Review payload requirements for passengers, equipment, and bed cargo
• Choose the proper Trailer Tow Package and towing equipment
• Compare available towing technology on XLT and Lariat models

Explore the 2026 Ford Ranger

The 2026 Ford Ranger provides towing and hauling capability for work, recreation, and everyday truck use. Properly equipped Ranger models can tow up to 7,500 pounds and offer a maximum available payload of 1,767 pounds, while Ranger Raptor combines specialized off-road performance with up to 5,510 pounds of towing capability. Available towing technology can also help drivers manage trailers when hitching, backing, and traveling with a load. Visit our 2026 Ford Ranger research hub to learn more about its trims, features, technology, and capabilities.

• Compare Ranger engines, drivetrains, and towing capacities.
• Review available trailering technology and equipment.
• Explore Ranger trims, features, and off-road capability.

*Maximum towing and payload ratings are for properly equipped vehicles and vary based on engine, drivetrain, vehicle configuration, accessories, cargo, passengers, and option content. Do not exceed the vehicle’s rated capacities. Trailer Tow Package is required for trailers over 3,500 pounds. Always consult the vehicle’s Owner’s Manual and current Ford towing information before towing. Confirm current specifications, equipment, and availability with your Sid Dillon Ford team.
